Asphalt Batching Plant
Saikrupa Roadtech Pvt. Ltd. is one of the leading asphalt batching plant manufacturers in India. We make cutting-edge asphalt mixer plants based on the current industry standards. With our batch mix plant, our clients can create asphalt mix as per their requirements.
As a renowned company of asphalt mixing plant manufacturers, we have come up with a unique design that improves thermal efficiency, lowers heat losses, aids power saving, reduces the thermal stresses on the drying drum, thus improving the burner efficiency. The burner itself comes specifically designed for the client company to meet definite protocols and the efficiency levels designed by us to ensure that our clients obtain the best product. We also make sure that our hot mix plant cost is perfectly affordable.
The ABM series of asphalt batching plants are renowned for their high efficiency, production capability, and low maintenance.
Technical Specification of Asphalt Batching Plant
| MODEL | ABM-80 | ABM-100 | ABM-120 | ABM-160 | ABM-180 | ABM-200 |
|---|---|---|---|---|---|---|
| PLANT CAPACITY (TPH)* | 80 t/h | 100 t/h | 120 t/h | 160 t/h | 180 t/h | 200 t/h |
| BATCH SIZE | 1000 kg | 1250 kg | 1500 kg | 2000 kg | 2250 kg | 2500 kg |
| CYCLE TIME | 45 sec | |||||
| UNIT | ||||||
| COLD FEED BINS (NO. OF BINS) | 4 | 4 | 4 | 4 | 4/5 | 4/5 |
| CHARGING CONVEYOR CAPACITY (TPH) | 100 t/h | 120 t/h | 140 t/h | 180 t/h | 200 t/h | 220 t/h |
| DRYER TYPE | 4W Friction drive | |||||
| BURNER TYPE | High pressure, fully automatic, modulating | |||||
| FUEL | Diesel / Light Diesel Oil/furnace oil | |||||
| HOT ELEVATOR CAPACITY (TPH) | 100 t/h | 120 t/h | 100 t/h | 180 t/h | 200 t/h | 220 t/h |
| TOWER UNIT | ||||||
| FILLER ELEVATOR CAPACITY | x | x | 21 t/h | 21 t/h | 25 t/h | 25 t/h |
| FILLER COMPRESSOR UNIT | 15 t/h | 15 t/h | x | x | x | x |
| NO. OF. DECK | 4 | 4 | 4 | 4 | 4/5 | 4/5 |
| SCREENING CAPACITY | 100 t/h | 120 t/h | 100 t/h | 180 t/h | 200 t/h | 220 t/h |
| HOT AGGREGATED | 4 | 4 | 4 | 4 | 4/5 | 4/5 |
| HOT AGGREGATED BIN UNIT (NO. OF BINS) | 1250 kg | 1500 kg | 1800 kg | 2500 kg | 2750 kg | 3250 kg |
| FILLER HOPPER CAPACITY | 150 kg | 150 kg | 200 kg | 200 kg | 300 kg | 300 kg |
| BITUMEN HOPPER CAPACITY | 150 kg | 150 kg | 200 kg | 200 kg | 300 kg | 300 kg |
| MIXTURE TYPE UNIT | Twin-shaft hot oil jacketed | |||||
| MIXTURE CAPACITY | 1500 kg | 1500 kg | 1800 kg | 2500 kg | 2750 kg | 3250 kg |
| AGGEREGATE HOPPER CAPACITY | ||||||
| PRIMARY TYPE | Centrifugal cyclone unit | |||||
| SECONDARY TYPE | Bag filter unit | |||||
| BAG FILTER TYPE | Reverse airflow | |||||
| FILTER AREA | 200m2 | 200m2 | 340m2 | 340m2 | 450m2 | 450m2 |
| CONTROL PANEL TYPE | Fully Synchronized with manual over-ride ( HMI/PLC Based) | |||||
| ACCESSORIES | ||||||
| BITUMEN TANKS (CAPACITY IN LITER) | 20000/30000/50000 | |||||
| HEATING SYSTEM | Direct heating / indirect heating | |||||
| THERMIC OIL | x | x | 200000/400000/600000 | |||
| THERMIC OIL | ✓ | ✓ | x | |||
| PLANT CAPACITY RATED AT: | ≤3% moisture content in cold aggregates, 38°C atmospheric temperature aggregated density of 1.6tons/m3 mean sea level, Ambient temperature of 35°C Hot mix temperature of 150°C |
|||||
